Applications
1. Petroleum, Chemical, and Natural Gas Industries
Petroleum extraction and refining: drilling platforms, oil production plants, refineries, gas stations, and oil pumping stations. These locations are filled with flammable and explosive substances such as crude oil, natural gas, gasoline, diesel, and hydrogen sulfide.
Chemical production: chemical plants, pesticide plants, fertilizer plants, pharmaceutical plants, paint plants, and resin plants. Large quantities of flammable and explosive chemical gases and dust are generated during production, processing, storage, and transportation.
Natural gas: natural gas processing plants, compressed natural gas (CNG)/liquefied natural gas (LNG) filling stations, and gas pipeline valve rooms.
2. Mining: Coal mines: underground tunnels, mining faces, ventilation openings, and transfer stations. Coal mines contain methane (gas) and coal dust, both of which are extremely potent explosion sources.
Other mines: metal mines (such as aluminum and magnesium powders) and sulfur mines also present combustible dust environments.
3. Military Industry and Aerospace
Production, storage, and testing sites for gunpowder, explosives, and ammunition.
Aerospace: Fuel filling stations, aircraft hangars (where fuel vapors may accumulate during maintenance), rocket propellant production plants, etc.
Standard Materials
Housing: GRP
Exterior: Stainless steel
Technical Parameters
| Type |
Plug & Receptacle |
| Ex Rate |
Ex d e IIC T6 Gb |
| Rated Current【A】 |
16 |
32 |
63 |
| Rated Voltage |
220/380VAC |
|
Degree of protection
|
IP66 |
| Entries |
M25*1.5 (suitable for
Φ8mm-Φ17mm cable)
|
M40*1.5 (suitable for
Φ13mm-Φ27mm cable)
|
M40*1.5 (suitable for
Φ13mm-Φ27mm cable)
|
| The cable for plug |
Φ8mm-Φ19mm |
Φ12mm-Φ28mm |
Φ12mm-Φ28mm |
