50W-300W Range Explosion Proof LED Light For Class I Division 1 Paint Booth Protection

I'm Online Chat Now

50W-300W Range Explosion Proof LED Light For Class I Division 1 Paint Booth Protection

50W-300W Range Explosion Proof LED Light For Class I Division 1 Paint Booth Protection
50W-300W Range Explosion Proof LED Light For Class I Division 1 Paint Booth Protection 50W-300W Range Explosion Proof LED Light For Class I Division 1 Paint Booth Protection

Large Image :  50W-300W Range Explosion Proof LED Light For Class I Division 1 Paint Booth Protection

Product Details:
Place of Origin: CHINA
Brand Name: CROWN EXTRA
Certification: IECEx,ATEX,CE,CNEX,ISO,RoHS
Model Number: GYD970-2
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: USD51/pc
Packaging Details: 1SET/CTN
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union
Supply Ability: 10000 Per Month

50W-300W Range Explosion Proof LED Light For Class I Division 1 Paint Booth Protection

Description
Highlight:

Paint Booth Explosion Proof LED Light

,

Explosion Proof LED Light 300W

,

Division 1 Paint Booth LED Light

Features:

◇environmental-friendly and eneray saving, simple shape, easy installation.

◇ constant current output, stable performance◇low power consumption, high light efficiency, good color rendering property

◇widely used in factories, warehouses, stadiums and other panoramic lighting.

Explosion Proof Led Lighting Applications

Typical applications include:
Oil and gas industries
Chemical, petrochemical
Pharmaceutical industries
Pulp and Paper
Waste and sewage treatment
Power Generation


Explosion Proof Led Lighting Specifiction:
European(ATEX) CE 1282 II 2G Ex n Re mb IIC T6
Gas and Dust CE1282 II 2D Ex td T80℃
For use in Zone 2& Zone 21,22
Rated voltage 100-240VAC, 50-60Н2
Power factor >0.95
THD <20%
Power consumption [W] 50-75 100 100-200 250-300
Colour renderina [CRI] 70 (+2)
Colour temperature [K] 6000-6500
Luminaire efficiency [Lm/W] 115-130
Beam angle 120° (60°,90° is optional, with lens)
Deqree of protection IP66
Cable entry G 3/4" NPT 3/4"
Weight [kg] 5.12 9 12 20
Terminal ≤2.5m㎡
Mounting Styles Ceiling; Wall Bracket; Pendant

Installation:

Before installation, Check voltage, power and other parameters carefully and make installation preparations arrordingly to layout circuit.1. organize firstly supporting spare parts and accessories.2. do shut off power before installation.3. the loading capacity of the ceiling fixed item where the lamp is installed should be the same as the lamp weight.4. do power-on test to make sure the lamp can be lighted.5. make sure the lamp is installed firmly, turn on the light finally.
