Explosion Proof Linear Light for Hazardous Areas | 9-54W Ex db IIC T6 | LED Fixture | Ceiling/Wall Mount, High Impact Resistance

I'm Online Chat Now

Explosion Proof Linear Light for Hazardous Areas | 9-54W Ex db IIC T6 | LED Fixture | Ceiling/Wall Mount, High Impact Resistance

Explosion Proof Linear Light for Hazardous Areas | 9-54W Ex db IIC T6 | LED Fixture | Ceiling/Wall Mount, High Impact Resistance
Explosion Proof Linear Light for Hazardous Areas | 9-54W Ex db IIC T6 | LED Fixture | Ceiling/Wall Mount, High Impact Resistance Explosion Proof Linear Light for Hazardous Areas | 9-54W Ex db IIC T6 | LED Fixture | Ceiling/Wall Mount, High Impact Resistance Explosion Proof Linear Light for Hazardous Areas | 9-54W Ex db IIC T6 | LED Fixture | Ceiling/Wall Mount, High Impact Resistance

Large Image :  Explosion Proof Linear Light for Hazardous Areas | 9-54W Ex db IIC T6 | LED Fixture | Ceiling/Wall Mount, High Impact Resistance

Product Details:
Place of Origin: CHINA
Brand Name: CROWN EXTRA
Certification: CE,IECEX,ROHS,ISO,ATEX,
Model Number: BYS-Explosion Proof Fluorescent Light
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD58PCS
Packaging Details: 142*25*17CM CTN
Delivery Time: 5-7 WORK DAYS
Payment Terms: T/T, Western Union
Supply Ability: 100000PCS PER MONTH

Explosion Proof Linear Light for Hazardous Areas | 9-54W Ex db IIC T6 | LED Fixture | Ceiling/Wall Mount, High Impact Resistance

Description
Ip Rating: IP65 Intended Use: Zone1 And 2, Zone 21 And 22
Lamp Type: Fluorescent Material: GRP
Frequency: 50/60Hz Mounting Options: Ceiling, Wall, Pendant
Watt: 1x9W、1x18W、2x9W、2x18W、3x9W、3*18W Color Temperature: 5500~6500K
Item Type: Explosion Proof Fluorescent Light Mounting: Ceiling, Wall, Flangle, Pendant
Efficiency: 100lm/w

Explosion Proof Linear Light (BYS Series) – High-Performance Lighting for Hazardous Environments

Key Features & Benefits

  • Robust Safety: Certified Ex db eb IIC T6 Gb / Ex tb IIIC T80°C Db, ideal for explosive atmospheres (Zone 1, 2, 21, 22).

  • Superior Durability: GSP material housing resists corrosion, impacts, and harsh chemicals.

  • Smart Safety Design: Built-in explosion-proof traveling switch with power-cut interlock when opened.

  • Emergency Ready: Optional 50-minute backup for critical operations.

  • High Efficiency: 100lm/W output, 5500K–6500K adjustable CCT, and CRI ≥70 for clear visibility.


Applications

Designed for industries where safety is non-negotiable:

  • Oil & Gas: Refineries, drilling rigs.

  • Chemical Plants: Corrosive vapor zones.

  • Mining: Underground tunnels with combustible dust.

  • Pharmaceutical: Sterile but volatile environments.


How It Works

The BYS Series integrates explosion-proof engineering with advanced LED technology:

  1. Sealed Housing: GSP material and tight buckle design prevent sparks from escaping.

  2. Thermal Management: Dissipates heat efficiently to maintain T6/T80°C ratings.

  3. Instant Illumination: LEDs activate immediately, even with emergency power.


Technical Specifications

Parameter Details
Model BYS-600 / BYS-1200
Power 9W/18W/27W (BYS-600) or 18W/36W/54W (BYS-1200)
Voltage 100V–277V AC (wide range compatibility)
Luminous Flux Up to 5400 lumens (BYS-1200 at 54W)
Beam Angle 120°–140° (wide coverage)
IP Rating IP66 (dustproof and resistant to powerful water jets)
CRI ≥70 (standard) / ≥80 (optional high-color accuracy)
Mounting Ceiling, wall, flange, or pendant (flexible installation)

Global Market Compliance

  • Certifications: ATEX, IECEx, UL (customizable for regional standards).

  • Voltage Adaptability: 100V–277V suits North America, Europe, and Asia.

  • Languages: Labels/documentation available in English, Spanish, Arabic.



Explosion Proof Linear Light for Hazardous Areas | 9-54W Ex db IIC T6 | LED Fixture | Ceiling/Wall Mount, High Impact Resistance 0

Explosion Proof Linear Light for Hazardous Areas | 9-54W Ex db IIC T6 | LED Fixture | Ceiling/Wall Mount, High Impact Resistance 1
