Product Details:
|
| Item Type: | Explosion Proof Fluorescent Light | Model: | BYS-600 |
|---|---|---|---|
| Power: | 9/18/27W | Working Temperature(℃):: | -40~60° |
| Tube Number: | 1 Tube, 2 Tubes And 3 Tubes | Ex Mark: | Ex Db Eb IIC T6 Gb/Ex Tb IIIC T80℃ Db |
| Corrosion Resistant: | WF2 | Efficiency: | 100lm/w |
| CRI: | Ra:≥70 | Mounting: | Pendant; Ceiling; Chain; Embedded; Wall; Stanchion |
| High Light: | 1450mm Tri proof Lamp,Corrosion Resistant Tri proof Lamp,Anti Explosive Tri proof Lamp |
||
This product has a size of L700*W700*H90, making it suitable for use in large spaces that require ample lighting. It is corrosion-resistant with a WF2 rating, ensuring that it can withstand exposure to corrosive substances without deteriorating. This feature makes it ideal for use in industries such as oil and gas, chemical, and marine where exposure to harsh chemicals is common.
The Anti-Explosive Fluorescent Lamp has a working lifetime of 50000H, making it a cost-effective lighting solution that requires minimal maintenance. Its frequency of 50/60Hz ensures that it can be used in a wide range of power supply systems without any issues.
The lamp's luminous efficiency is 100lm/w, providing bright and clear illumination that is perfect for hazardous environments. It is designed to distribute light evenly, ensuring that all areas are well-lit and visible. This makes it ideal for use in areas where safety is of utmost importance, such as chemical plants, oil refineries, and mining sites.
In conclusion, the Anti-Explosive Fluorescent Lamp is an excellent lighting solution for hazardous environments. Its Explosion Proof Fluorescent Light design, corrosion-resistant materials, and long working lifetime make it a cost-effective and reliable choice for industries that require lighting solutions that can withstand harsh conditions. Whether you need to light up a large space or a small area, this lamp is a perfect fit for your needs.
This Blast Resistant Fluorescent Light Bulb is designed for use in hazardous locations where there is a risk of explosion. The Explosion-Proof Fluorescent Lighting System has a beam angle of 120-140℃ and a working life time of 50000H. It also has a Protection Class Level of Safety Class Ⅱ and an Ex Mark of Ex Db Eb IIC T6 Gb/Ex Tb IIIC T80℃ Db. This makes it suitable for use in Zone1 And 2, Zone 21 And 22.
| Model No. | BYS600 | BYS1200 |
| T8 Fluorescent Tube | (1~3)*18W(1350Lm, 75lm/W) | (1~3)*36W(2700Lm, 75lm/W) |
| T5 Fluorescent Tube | (1~3)*14W(1350Lm, 96lm/W) | (1~3)*28W(2100Lm, 75lm/W) |
| LED Tube | (1~3)*8W(800Lm, 100lm/W) | (1~3)*18W(1800Lm, 100lm/W) |
| Ex Marking | Ex d e IIC T6 Gb/Ex tD a21 IP66 T80℃ |
| Classification | Group II, Catogory 2 GD; Class I, Division 1 and 2,Group A,B,C,D; |
| IP Degree | IP66 |
| Corrosion Resistant | WF2 |
| Rated Voltage | 110~220VAC, 50~60HZ |
| Conduit Entries | G 3/4" |
| Temperature | T6~T8 |
| Mounting Styles | Pendant; Ceiling; Chain; Embedded; Wall; Stanchion |
The BYS Explosion Resistant Fluorescent Light Fixture is a versatile lighting solution that can be used in a wide range of industrial, commercial, and institutional settings. It is particularly suitable for areas where flammable materials are processed, stored, or transported, such as oil and gas refineries, chemical plants, grain silos, or mines. The BYS Explosion Proof Fluorescent Light is also ideal for use in marine or offshore installations, where corrosive or salt-laden environments can cause premature equipment failure.
The Crown Extra BYS Explosion-Proof Fluorescent Lighting System is available in two lengths: 600mm and 1200mm, and has a frequency of 50/60Hz with a power factor of 0.98. The Cable Specifications are 9~14mm. The minimum order quantity is 1SET and pricing ranges from $50.00-$80.00. The packing list includes 1SET/CTN and dimensions of 1450*250*170mm, 11kg. Delivery time is 5-10 days and payment terms are 50%+50%. The product has a supply ability of 5000SET/Month.
Whether you need to light up a large factory floor or a confined space, the Crown Extra BYS Explosion-Proof Fluorescent Lighting System is an excellent choice. It is easy to install, maintain, and operate, and comes with a comprehensive warranty that covers all manufacturing defects. The BYS Explosion Proof Fluorescent Light is built to last and withstand harsh environmental conditions, making it a reliable and cost-effective lighting solution for any workplace.
Our minimum order quantity is 1SET and the packaging details include 1SET/CTN. The price range for our Explosion Proof Fluorescent Light is $50.00-$80.00 and the delivery time is 5-10 days. Payment terms include 50%+50% and we have a supply ability of 5000SET/month. Contact us today to customize your lighting solution!
Our Explosion Proof Fluorescent Light product comes with comprehensive technical support and services to ensure optimal performance and safety. Our team of experts can assist you with:
We are committed to providing reliable and efficient support to our customers and ensuring the longevity and functionality of our products.
Q: What is the brand name of this Explosion Proof Fluorescent Light?
A: The brand name of this product is Crown Extra.
Q: What is the model number of this Explosion Proof Fluorescent Light?
A: The model number of this product is BYS.
Q: Where is this Explosion Proof Fluorescent Light manufactured?
A: This product is manufactured in China.
Q: What certification does this Explosion Proof Fluorescent Light have?
A: This product has ATEX certification.
Q: What is the minimum order quantity for this Explosion Proof Fluorescent Light?
A: The minimum order quantity for this product is 1SET.
Q: What is the price range for this Explosion Proof Fluorescent Light?
A: The price range for this product is $50.00-$80.00.
Q: What are the packaging details for this Explosion Proof Fluorescent Light?
A: The packaging details for this product are 1SET/CTN.
Q: What is the delivery time for this Explosion Proof Fluorescent Light?
A: The delivery time for this product is 5-10 days.
Q: What are the payment terms for this Explosion Proof Fluorescent Light?
A: The payment terms for this product are 50%+50%.
Q: What is the supply ability for this Explosion Proof Fluorescent Light?
A: The supply ability for this product is 5000SET/month.
