Product Details:
Place of Origin: China
Brand Name: Crown Extra
Certification: ATEX
Model Number: BPY-1200
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: USD43.5PCS
Packaging Details: CARTON、WOODEN BOX、PALLET
Delivery Time: 7-15 working days
Payment Terms: T/T, Western Union
Supply Ability: 50000pcs/month

Hot selling explosion proof linear light 18-36W 1200mm ex-proof fluorescent light with high anti-corrosion performance

Description
Ex Mark: Ex Db Eb IIC T6 Gb/Ex Tb IIIC T80℃ Db Power: 18-36W
Corrosion Resistant: WF2 Beam Angle: 120-140°
Mounting: Ceiling, Wall, Flangle, Pendant European (ATEX) Ex De IIC T6Gb Input Voltage: 220VAC, 50-60Hz
Type: BPY-1200 (Single/Double) CRI: Ra:≥70
High Light:

54w Fluorescent Light Fixture

,

CE Certification Fluorescent Light Fixture

,

Hazardous Areas Fluorescent Light Fixture

Hot selling explosion proof linear light 18-36W 1200mm ex-proof fluorescent light with high anti-corrosion performance

Hot selling explosion proof linear light 18-36W 1200mm ex-proof fluorescent light with high anti-corrosion performance 0



Features:

1. Die casting aluminum shell, with high voltage electrostatic plastic-spraysurface.

2. Easy to change the tube, just remove the end cover to change.
3. Electronic ballast, improve the power factor largely, COS>0.95
4. Tempered glass lamp shade, stainless steel exposed fastener.
5. Steel pipe wiring or cable wiring




Applications


A wide range of hazardous areas where ignitable vapors, dust, moisture and corrosive elements are present
Areas requiring frequent on-and-off of lights or power cycling- no warm up time required
Typical applications include:
Oil and gas industries
Chemical, petrochemical
Pharmaceutical industries
Pulp and Paper
Waste and sewage treatment
Power Generation
Other high humidity, high dust, high temperature, vapor locations




Standard Materials
Housing: Die-cast aluminum
Exterior: Stainless steel
Globe: Tempered glass





Certifications
ATEX
CNEX
CE
RoHS
ISO9001



Hot selling explosion proof linear light 18-36W 1200mm ex-proof fluorescent light with high anti-corrosion performance 1





Electrical Data
Ex Marking Ex d e IIC T6 Gb/ DIP A21 TA
Classification Group II, Catogory 2 GD; Class I, Division 1 and 2,Group A,B,C,D; Zone 1, 2 & Zone 21, 22
IP Degree IP66
Corrosion Resistant WF1
Input Voltage 90-305VAC/50~60HZ or 24V DC
Battery Back-up Optional, Emergency time>90min;Charging time:24h;Starting time:0.3s
Conduit Entries G 3/4"
Terminal ≤2.5mm2
Mounting Styles Pendant; Ceiling; Chain; Embedded; Wall; Stanchion




Ordering Information
Model NO. BPY-I BPY-II BPY-III
T8Fluorescent tube 20Wat 30Watt 40Wat
T5 Fluorescent tube 14Watt 21Watt 28Watt
LED tube 8Watt 12Watt 18Watt


Hot selling explosion proof linear light 18-36W 1200mm ex-proof fluorescent light with high anti-corrosion performance 2



Installation Instructions:
Before installation, check voltage, power and other parameters carefully and
make installation preparations arrordingly to layout circuit.
1. organize firstly supporting spare parts and accessories
2. do shut off power before installation
3. the loading capacity of the ceilingfixed item where the lamp is installed should be the same as the lamp weight
4. do power-on test to make sure the lamp can be lighted
5. make sure the lamp is installed firmly, turn on the light finally
Company information:
Crown Extra Lighting Co., Ltd. is a comprehensive enterprise integrating R&D, production, sales and service.
The company is located in Changzhou, known as the "Dragon City" in the Yangtze River
Delta of China. The company is committed to becoming a provider of green, environmentally friendly,
energy-saving, and leading industrial lighting solutions, providing high-quality lighting products for
petroleum, petrochemical, electric power, metallurgy, railways, aerospace, military, public security,
fire fighting, ships, roads, pharmaceuticals, etc. And professional technical service programs.
FAQ:
Q1. Can I have a sample order for explosion-proof led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2: What kind of payments do you accept?
A:T/T, L/C, Western Union,, MoneyGram, etc..
Q3:What is you main products?
A: Explosion-proof LED light ,explosion-proof box,explosion proof fittings, etc.
Q4: Do you offer guarantee for the products?
A: Yes, we offer 3-5 years warranty to our products.
Q5: What's the MOQ?
A:MOQ is 1 set.
