Gas Station Tunnel LED High Bay Explosion Proof Emergency Light 132lm W

Certification
China crown extra lighting co. ltd certification
China crown extra lighting co. ltd certification
I'm Online Chat Now

Gas Station Tunnel LED High Bay Explosion Proof Emergency Light 132lm W

Gas Station Tunnel LED High Bay Explosion Proof Emergency Light 132lm W
Gas Station Tunnel LED High Bay Explosion Proof Emergency Light 132lm W Gas Station Tunnel LED High Bay Explosion Proof Emergency Light 132lm W

Large Image :  Gas Station Tunnel LED High Bay Explosion Proof Emergency Light 132lm W

Product Details:
Place of Origin: China,Jiangsu
Brand Name: Crown Extra
Certification: CE, ROHS, ISO. ATEX,
Model Number: GYD8101
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: usd68 per piece
Packaging Details: Led Lights will be packed in carton, pallet
Delivery Time: 7 working days
Payment Terms: T/T, Western Union
Supply Ability: 2000 pieces per month

Gas Station Tunnel LED High Bay Explosion Proof Emergency Light 132lm W

Description
Product Name: Explosion Proof High Bay Led Lights Material: Aluminum Alloy
Color Temperature(CCT): 6000K Lamp Luminous Efficiency: 132 Lm/w
CRI (Ra>): 72 Working Temperature: -20℃-55℃
Application Area: Zone 2,21,22 Driver Brand: MEANWELL/DONE
Light Source: CREE Work Time: 50000 Hours
High Light:

Gas Station Tunnel LED High Bay Explosion Proof

,

LED High Bay Explosion Proof 132lm W

,

flameproof high bay light 132lm W

Chemical Industry Gas Station Tunnel LED High Bay Explosion Proof Lighting/Lights



Features:

Aluminium alloy Enclosure,high voltage electrostatic powder coated after shot blasted.
High strength toughened glass cover.
Exposed fasteners are of stainless steel with function of high corrosion-proof.
With grids to adjust lighting effect and reduce the glare.
Modular plug structure design, only need disconnect end cover draw out core to change tubes.
For fitting with emergency unit, It will automatically turn to emergency lighting when power circuit failed.
Inside the emergency unit designed with over charging and over discharging protection circuit.
Screw connection type, for easy installation and maintenance.
Steel conduit or cable wirings.




Application:



1. Explosive gas mixture hazardous locations: Zone 1 and Zone 2.
2. Explosive gas mixtures: IIA, IIB, IIC.
3, flammable dust environment:20,21,22 area
4, explosion-proof signs: ExdeIIBT6, ExdeIICT6
5.often be used in chemical plant,gas station,oil station,workshop,warehouse,pharmaceuticals,smelting, shipbuilding, military, textile and other flammable and explosive places




Specification:


ELECTRIC
Operating voltage AC 110-240V (50Hz) Power consumption 50W/80W/100W/150W/240W
MECHANICAL
Humidity 10%~95%RH Anti-corrosion WF1
Operating temperature -30 ̊C ~ +50 ̊C Cable entry M25*1.5/NPT 3/4”cable entry, suitable for ø10 ~ ø14mm² cable ≤2.5mm² conductor
Weight 4.8Kg IP Class IP65
Installation Bracket mount, ceiling mount, 60° wall mount, 90° wall mount, guardrail mount, flange mount
CERTIFICATION LABEL
Standard GB3836.1-2010,GB3836.2-2010, GB12476.1-2000,
IEC60079-0:2011, IEC60079-1:2007,IEC60079-31:2008,
EN60079-0:2009,EN60079-1:2007,EN60079-31:2009



FAQ:


1. How do you ensure your products quality and service?

All our production process strictly adhere to ISO9001 procedure, and we also offer clients 3-5 years warranty from the date which B/L issued. If the products doesn’t work properly as promised, and the problem is caused by the quality issue, we will provide exchange service.



2. Can you make the products according to custom requirement?

Yes, we can provide bespoke service to custom exact specification. You can send us the detailed specification of the products you are in need and our engineer team will check whether it is workable for us. Or you can send us the samples and our engineer team can understand it better.



3. Can I just buy 1 pc of sample for testing before place the bulk orders?

Yes, samples orders are always welcome, we are confident on our lights quality and we believe that you will place bulk order to us once you test our samples.



4. What is your delivery time?

If in stock,  within 5 days after your deposit.
If without stock,  it will be within 10-15 days.
