Product Details:
|
| Product Name: | Explosion Proof High Bay Led Lights | Material: | Die-casting Aluminum |
|---|---|---|---|
| Color Temperature(CCT): | 5800K | Lamp Luminous Efficiency: | 130 Lm/w |
| CRI (Ra>): | 70 | Working Temperature: | -20℃-50℃ |
| Application Area: | Zone 2,21,22 | Driver Brand: | MEANWELL/DONE |
| Light Source: | CREE | Work Time: | 50000 Hours |
| High Light: | 150W Explosion Proof High Bay LED Light,Explosion Proof High Bay LED Light emergency 120w,120w led high bay lights |
||
Gas Station Lamp Explosion Proof Led High Bay Lights 120w With Emergency Device
Features:
1.Shell made of high strength aluminum alloy casting off surface after blast cleaning by high voltage electrostatic spray.
2.Lamp housing is made of high borosilicate toughened glass with transmittance.It's the antiglare design.
After designed by special software design of distribution for two times,it can get the comfirmation.
3.Exposed fasteners are of stainless steel with function of high corrosion-proof.
4.With grids to adjust lighting effect and reduce the glare.
5.Modular plug structure design, only need disconnect end cover draw out core to change tubes.
6.For fitting with emergency unit, It will automatically turn to emergency lighting when power circuit failed.
7.Inside the emergency unit designed with over charging and over discharging protection circuit.
8.Screw connection type, for easy installation and maintenance.
Application:
| Oil and Gas industry |
| 1. All petroleum production and refining |
| 2. Petroleum storage and retail |
| Chemical industry |
| 1. All types of paint facilities |
| 2. Chemical production and storage |
| Metal treatment |
| 1. Steel and aluminum factories |
| 2. Pumping stations in any environment |
| 3. Metal smelting, foundry and fabrication |
| Food and alcohol industry |
| 1. Flour and fine particle production and storage |
| 2. Food and distilling production |
| 3. Alcohol industry |
| Other high humidity, high dust, high temperature, vapor locations |
Specification:
| European (ATEX) Gas and Dust | II 2G Ex nR e IIC T6 II 2D Ex td T80℃ |
||||||
| For use in | Zone 2 & Zone 21, 22 | ||||||
| Electrical data | |||||||
| Rated voltage | 100-240VAC, 50-60Hz | ||||||
| Power factor | >0.95 | ||||||
| THD | <20% | ||||||
| Luminous characteristics | |||||||
| Power consumption [W] | 20～70 | 80-100 | 100-200 | 220-300 | |||
| Colour rendering [CRI] | 70 | ||||||
| Colour temperature | 5800 | ||||||
| Luminaire efficiency [Lm/W] | 130 | ||||||
| Beam angle | 60 | ||||||
| Mechanical data | |||||||
| Degree of protection | IP65 | ||||||
| Cable entry | G 3/4” | ||||||
| Weight [kg] | 4.8 | 6.4 | 8.8 | / | |||
| Terminal | ≤2.5 mm² | ||||||
| Mounting Styles | Ceiling; Wall Bracket; flange | ||||||
Installation Instructions
Before installation, check voltage, power and other parameters carefully and make installation preparations arrordingly to layout circuit.
1. organize firstly supporting spare parts and accessories
2. do shut off power before installation
3. the loading capacity of the ceilingfixed item where the lamp is installed should be the same as the lamp weight
4. do power-on test to make sure the lamp can be lighted
5. make sure the lamp is installed firmly, turn on the light finally
